Wednesday, May 1, 2013

ViewSonic VP2770-LED

Today we're taking a look at the VP2770-LED monitor from ViewSonic. It's a 27" monster monitor we first set eyes on at CES 2013. Usually as the inches increase so do the pixels and this is definitely the case for the VP2770-LED which sports a solid 2560x1440 pixels.

Specifications
The VP2770-LED is a well equipped monitor with a large list of features. There are several input connections, USB 2.0/3.0 connections, wide viewing angles and many more features you can see in the list below.

LCD

Type27" Wide Color TFT Active Matrix LED
Display Area23.5" horizontal x 13.2" vertical; 27" diagonal
Optimum Resolution2560x1440 (DisplayPort, Dual-Link DVI-D)
Contrast Ratio1000:1 (typ.)
Brightness300 cd/m2 (typ.)
Viewing Angles178º horizontal, 178º vertical
Response Time12ms (typ)
Light Source30,000 hours (min.)
Panel SurfaceAnti-glare, hard-coating (3H)
BacklightWhite-light LED
Dynamic Contrast Ratio20,000,000:1
Colors1.07 billion (8 bits + 2 bits FRC) with DisplayPort and Dual-Link DVI

COMPATIBILITY

PCPC compatibles (from VGA up to 2560x1440 non-interlaced)
Mac®Up to 2560x1440

REGULATIONS

CE,CB, BSMI, PSB, SASO, C-tick, e-standby, KC, UL/cUL, FCC-B (including ICES003), UL CoC, Mexico Energy, GOST-R/Hygienic, UkrSEPRO, Erp, CCC, ENERGY STAR®, China Energy, EPEAT Silver, WEEE, RoHS, SVHC list

CONNECTOR

Analog15-pin mini D-sub (VGA)
DigitalHDMI (V1.4 with HDCP) DVI-D (with HDCP) DisplayPort
Audio Out3.5 mm jack
PowerInternal power supply
USBUSB 2.0 (x2), USB 3.0 (x2), USB Upstream

POWER

VoltageAC 100–240V (universal), 50 / 60Hz
Consumption40W (typ)
Optimize30W (typ)
Conserve22W (typ)

RECYCLE/DISPOSAL

Please dispose of in accordance with local, state or federal laws.

CONTROLS

OSDAuto Image Adjust, Contrast/Brightness, Input Select (D-SUB, DVI, Displayport, HDMI), Audio Adjust (Volume, Mute - for audio output), Color Adjust (sRGB, Bluish, Cool, Native, Warm, User Color [R,G,B]), Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine Tune, Sharpness, Dynamic Contrast, Response Time, Aspect Ratio, Overscan, ECO-mode), Setup Menu (Language, Resolution Notice, OSD Position, OSD Timeout, OSD Background, Auto Power Off, Sleep, Power Indicator), Memory Recall
PanelPower, 1, up, down, 2

PACKAGE CONTENTS

VP2770-LED monitor, power cable, Dual Link DVI cable, VGA cable, DP cable, USB 3.0 cable, User Guide, Quick Start Guide, ViewSonic Wizard CD-ROM

OPERATING CONDITIONS

Temperature32–104º F (0–40º C)
Humidity20–90% (non-condensing)

WARRANTY

Three-year limited warranty on parts, labor and backlight.

VIDEO INPUT

AnalogRGB analog (0.7 / 1.0 Vp-p, 75 ohms)
DigitalDVI-D (TMDS, 100 ohms), DisplayPort, HDMI 1.4
FrequencyFh: 24~92kHz, Fv: 50~75Hz
SyncSeparate Sync

DIMENSIONS (WxHxD)

Physical With Stand25.3 x 18.5 x 13.7 in. / 642.6 x 464.8 x 348 mm
Physical Without Stand25.3 x 15.0 x 2.2 in. / 642.6 x 381 x 56 mm
Packaging28.8 x 22.4 x 17.8 in. / 732 x 570 x 451 mm

ERGONOMICS

TiltForward 5º, Back 20º
Swivel±60º
Height Adjust0–5.9" / 0–150mm
Pivot0–90º

WEIGHT

Weight18.6 lb. / 8.5 kg
Gross25.1 lb. / 11.4 kg
Net Without Stand12.8 lb. / 5.8 kg

Build Quality
The stand which comes with the VP2770-LED is sturdy enough to support such a large screen. The stand can pivot, it allows variable heights and it provides tilt and rotate to position the monitor any way you would want. The only drawback is size. You will need to make sure you have plenty of space for this stand and its monitor.




On the bottom of the monitor on the left hand side are the display and audio connections. The monitor comes with VGA, DVI, HDMI and Display Port connections. It's nice to have so many options to choose from especially if you plan on toggling between multiple computers/devices.

On the bottom right side of the monitor you will find the power connection, the USB plug which connects to the computer and then two standard USB slots for connecting peripherals.

On the right hand side there are two additional USB slots which as you can see are USB 3.0 giving you easy access to plug in your ultra fast USB drives or any other peripherals that might take advantage of the extra speed.


On the front of the monitor in the bottom right corner you'll find all of the menu navigation buttons and the power button. These are touch sensitive buttons which give the monitor an elegant feel and they are very responsive.

Menu Features
The menu system is easy to navigate and provides all the features you would expect from a monitor of this caliber. To start off there are adjustments for contrast and brightness.









The next set of options is for toggling between the display's connected devices. Honestly though this menu option is probably not one you will use. Toggling between connected devices can be done quickly by pressing the number 2 touch sensitive button when there is no on screen display (OSD).








The VP2770-LED comes equipped with speakers and you can adjust the volume levels from here. To get here quickly you can press the touch sensitive down arrow when there is no OSD showing and it will bring you right to these settings.








ViewSonic has pre-calibrated this IPS display. The color accuracy will probably be good enough for most; however, if you plan to use this monitor for a job that requires precise accuracy of color then you will want to use the color adjustment screens while you calibrate your monitor for the most accurate colors.








The information screen will give you some of the basic information about the display. Not much to see here that wasn't listed in the specifications section.








The manual image adjust settings is where you will find options to customize the sharpness, contrast, response time, aspect ratio, overscan, eco mode and gamma settings. The response time options are: standard, advanced and ultra fast. We set ours to ultra fast.


The setup menu provides standard options to customize position, time out, etc. of the OSD.











Pressing the up arrow when no OSD is showing will give you a quick way to toggle between different settings you've saved and the factory settings.

Usage
As a hobby photographer I took advantage of the 27" display and higher resolution for editing images in Lightroom. The additional screen real estate made it easy to work with my raw images taken at higher resolutions. The VP2770-LED is a perfect solution for anyone that's in to photography.

As a software developer I spend quite a bit of time in Visual Studio and Eclipse. With a resolution of 2560x1440 I could comfortably place code side by side in a split screen setup. Normally this would cause an undesirable amount of horizontal scrolling. The VP2770-LED provides an additional 640 horizontal pixels (*coming from a 1920x1080 display)  to work with which is just enough to comfortably code in a split screen environment. I always like to have 2 monitors while coding, but I found myself using the secondary monitor much less because of the extra screen real estate. I don't know if my desk would forgive me, but two of these beauties side by side would be any developer's dream!

I watched several shows and played many hours of games using the VP2770. The slower response time and  refresh rate are not going to be appealing to any hard core gamer, but I won plenty of rounds all the same and enjoyed doing it on a 27" IPS display too. Watching movies or TV shows on the 27" is a pleasure. The slower response time and refresh rate don't give you the surreal feeling you get when watching a show on a 120Hz or 240Hz display; however, the 27 inches and higher resolution sure helps make up for that.

Conclusion
ViewSonic's VP2770-LED monitor is perfect for anyone involved in content creation. If you're in front of a computer frequently to code, work with images or any other form of content creation then this monitor is our top choice. If you're looking for a monitor purely for content consumption, the VP2770-LED is still a solid choice at this size, higher resolution and price point. The ViewSonic VP2770-LED's price point and features make it one of the best in its class. We've awarded the ViewSonic VP2770-LED our Editors Choice Award for its long list of features and superior build.




Read more!

Tuesday, April 30, 2013

2013 Headphone Shootout Part 2: The IEM's


It is now time for part 2 of our Headphone Shootout – the IEM’s. This year we have some great models, from a conservative $65 MSRP, to an elite $1000 MSRP. IEM’s are In-Ear-Monitors, and they are much better than the ultra cheap earbuds that came with your cell phone or MP3 player. The brands covered today include Outdoor Research, Audiofly, Monster, RBH, Westone, and ACS.

As mentioned in part one of the shootout, we do this around the time of March Madness. We figure with basketball teams duking it out, let’s get some headphones duking it out with each other. There are no brackets here, just price points. And manufacturers typically get it right at the price points. But just like there is in March Madness, where a lower bracket takes out an upper bracket, a lower priced IEM could perform better than an upper priced model. Let's find out.

First up is a pair of IEM’s from Outdoor Technology called Tags. The Tags are actually a wireless system using Bluetooth. At an $65 MSRP, that is a great value!

Features and specs:

-Rechargeable lithium-ion battery
-Pause and playback automatically when receiving calls
-Mini USB connector included for charging via USB port
-Skip songs and control volume
-Plus type: 8 pin mini USB
-Operating distance: up to 30 feet
-Operating time: Talk- 6 hours/Play music: 5 hours
-Standby time: 120
-Driver size: 8mm
-Impedance: 16 ohms
-Sound pressure level: 104db
-Frequency response: 10Hz-20000Hz
-Normal Input power: 2mW
-Max input power: 4mW
-THD:  (Total Harmonic Distortion): less than .5%

The Outdoor Research Tags come in a plastic package, so you can see the product. Included is a charging cable, additional ear tips and a soft storage bag. Quality of materials, as well as fit and finish were good. The earbuds had a soft plastic finish. The buttons had a good feel to them. So far I am impressed at their price point.

First up in the listening was Brunson Brothers: Fleace Movae.  Trumpets sounded crisp and clean, and just a tad bright.  Percussion was also fairly crisp.  Bass had good output, and was a bit muddy.  Fresh Aire II: Going to Another Place, the acoustic guitars and percussion were crisp.  The piano sounded fairly natural.  The flute however while it sounded ok, did not have much air.  And the bass had good output, but was a bit muddy.  Steve Miller Band: Swingtown, had fairly crisp percussion.  Bass guitar had nice output and depth, but again was a bit muddy.  Vocals sounded natural.  No Doubt: Hellagood, was dynamic in the percussion.  Bass had very good output and extension.  Vocals were clean but a tad bright.  These are wireless bluetooth earbuds and there was no 3.5mm jack.  So they can only be used with a source unit with bluetooth.  And reliability could vary depending on your source unit.  I used my laptop, and while it worked well when I was close, the music would cut out when I got over 10 feet away.  But again, that could vary based on what your source unit it and it's performance.

Next up is a pair of Audiofly AF56. Audiofly is a fairly new company out of Australia, and are doing some good things with IEM’s. The AF56’s are a traditional IEM design with in-line mic. They also feature a cloth cable.  MSRP is $100.

Features and specs:

-Machined anodized alloy bezel with precision laser cut venting for acoustic optimization
-Elongated one piece thermoplastic housing
-Custom voiced 11mm dynamic driver
-Cable strain relief with right hand braille marker
-Streamlined sound port to minimize sound eddies
-High grade silicon tips for a customized fit
-Magnet Type: Neodymium
-Frequency Range: 18-20KHz
-Cable Length: 1.2m
-Plug Type: 3.5mm gold plated
-Impedance: 16 Ohms
-Sensitivity: 118dB at 1kHz

The Audiofly AF56 come in a printed plastic packaging. They came with an owner's manual, additional ear tips, and a storage tin. Quality of materials and fit and finish were good. I liked the cloth cable.

Brunson Brothers: Fleace Movae, percussion was crisp, trumpets were smooth, bass was deep, and the resolution and imaging was good.  Fresh Aire II: Going to Another Place showed very crisp guitars.  The flute had a lot of air.  The soundstage was quite large.  Imaging was very good.  Drums had very good depth and impact.  $100 headphones should not sound this good.  Steve Miller Band: Swingtown, provided crisp cymbals, and the piano sounded natural.  Vocals were smooth with nice timbre, and the guitar was very accurate.  No Doubt: Hellagood was very dynamic in the percussion.  Bass had very good extension and played tight with a lot of authority.  Vocals were very natural sounding.  Not only did they sound great, but with the design they fit great and was easy to put in.

Monster Cable makes some excellent products as I have seen from their more premium headphones. I was excited to have their DNA IEM's included, which are at a more modest $110 MSRP. They are standard IEM design with in-line mic and controls. But being a Monster product, they are anything but standard.

Features and specs:


In-ear design

In-line controls.

Flat, tangle-resistant ControlTalk cord

5 pairs of multiple-size ear tips

Warranty Terms - Parts: 1 year
Warranty Terms - Labor: 1 year
Sound Isolating: No
Warranty Term - Parts: 1 year
Color: Black/Satin Chrome

As Monster has with their other headphone products, the Monster DNA IEM’s came in attractive packaging with a good presentation. Lifting up the cloth tab showed the IEM’s, a small velvet like storage bag, several sets of different sized ear tips, as well as owner's manual. Quality of materials as well as fit and finish were very good. The white soft plastic cable was of a tangle free design. The gloss white housings looked elegant and well put together. The button had a good feel.

Brunson Brothers: Fleace Movae had nice resolution in the percussion and acoustic guitar.  Trumpets were very clean and smooth without being too brassy.  Bass had good extension with sufficient output.  Fresh Aire II: Going to Another Place had very good resolution in the guitars.  The flute had good air.  The drums had good impact and depth, including dynamics.  Low level harmonics were quite good.  Steve Miller Band: Swingtown, the cymbals were crisp.  They also had nice low end extension in the bass.  Vocals portrayed good texture.  No Doubt: Hellagood, the percussion was crisp and dynamic.  Bass had good punch and authority.  Vocals were quite natural sounding and projected some nice harmonics.

RBH is well known for their excellent home speakers, and rightfully so with their superior products. Now they are selling headphones. Included in this year's shootout is a pair of their EP2 IEM’s.  The EP2 features an aluminum housing, and is the model with the in-line mic and controls.  With an MSRP of $179, they appear to be aggressively priced.



Features and specs:

-Driver Size:  13mm Dynamic Dome
-Impedance:  16 Ohms
-Frequency Range:  14Hz-18KHz
-Sensitivity:  101dB
-Noise Isolation:  16dB w/ Comply™ Foam Tips
-Input:  3.5mm Mini-jack
-Cable Length:  1.2m
-Color:  Black/Silver

The RBH EP2’s came in elegant looking black box with custom cutout foam to hold the IEM’s and storage case.   Also included were owners manual, sticker, leather storage case, and additional ear tips. The quality of materials as well as the fit and finish were very good. I liked the aluminum construction in the housing as well as the mic and switch housing. The cloth covered cable was also very nice.

Brunson Brothers: Fleace Movae had a very crisp and clean sound.  Trumpets were smooth and not too brassy.  Resolution was very good with a pleasantly large soundstage and good imaging. Bass extension was also low.  Fresh Aire II: Going to Another Place, was very crisp and clean in the acoustic guitar.  Resolution was very good, with a refined sound.  The flute had good air.  Piano was natural sounding.  Imaging was also very good.  Steve Miller Band: Swingtown, had very crisp cymbals.  Bass had great depth and played with authority.  Vocals were smooth with nice texture.  Imaging was also very good.  No Doubt: Hellagood, had very good dynamics in the percussion.  The bass had nice impact and gave it freely.  Vocals had a lot of energy, very good resolution, and was just a tad on the bright side.
Westone is a premium IEM manufacturer, and have been for many years.  They first began by manufacturing and selling hearing aids. Now they sell premium and custom IEM’s, and have been doing that for years as well. They sell both single and multiple driver models.  They provided the UM3X RC and 4R. The UM3X RC is the top of the line in their Universal Monitor Series, which are handmade and designed for the performing artist.  The 4R is part of their Universal Personal Listening series, and is designed for the serious audiophile. First up is their UM3X RC, with a $575 MSRP.

 Features and specs:
-Triple Balanced Armature Drivers Earphone With Passive Crossover
- 25 db Ambient Noise Reduction
- Removable 50" Stereo "Y" Cord
-3.5mm Stereo Jack
-Sensitivity:  124dB @ 1mW
-Frequency Response:  12Hz - 18kHz
-Impedance:  56 ohms @ 1kHz


The Westone UM3X RC came in a nice printed box which included photos of the product and it’s specs. I really likes the small window so you could look in and see the product. The Westone UM3X RC came with owner's manual, multiple sized ear tips, wax loop, and cloth case with an internal pocket. The materials used as well as the fit and finish are excellent. From the plastic housing to the cables and connections, the quality was excellent. And I really liked the clear plastic housing, so you can see the internal components. It was really cool!



Brunson Brothers: Fleace Movae provided excellent resolution.  Trumpets were extremely clean, and the percussion was very crisp.  They threw a large soundstage with precise imaging.  Piano was also very natural.  Fresh Aire II: Going to Another Place, the sound was so crisp and clean, with layers of resolution.  I loved being able to hear the transition of the strings as they were initially plucked and begin to subside.  The soundstage was large and imaging was dead on!  Dynamics were also excellent and drums had nice impact.  Steve Miller Band: Swingtown, had excellent resolution in the percussion as well as guitar.  Vocals were so life-like, I thought I was there in the recording studio.  Bass played with authority and great extension.  The piano and guitar was very dynamic.  No Doubt: Hellagood, percussion was extremely clean and dynamic.  Bass had nice extension and played with authority.  Vocals had excellent texture.  The resolution was amazing!

Next up is the Westone 4R. They are similar in design to the UM3X RC. The 4R’s do not have the clear plastic housing as the UM3X RC. Although the 4Rs do have a 4 driver design, with 2 bass driver instead of the one in the UM3X RC. They have a MSRP of $710.

Features and specs:

-Four Balanced Armature Drivers Earphone With Passive Crossover
-3.5mm Stereo Jack
-Sensitivity:  118dB @ 1mW
-Frequency Response:  10Hz - 18kHz
-Impedance:  31 ohms @ 1kHz Sensitivity: 118 dB SPL @ 1Mw
Frequency Response: 10Hz - 18kHz
Impedance: 31 ohms @ 1kHz
Driver: Four balanced armature drivers
Cable: EPIC removable cable
Features: Crush resistant travel case, assorted eartips, 1/8” to 1/4” adapter, inline volume attenuator and wax loop for cleaningSensitivity: 118 dB SPL @ 1Mw
Frequency Response: 10Hz - 18kHz
Impedance: 31 ohms @ 1kHz
Driver: Four balanced armature drivers
Cable: EPIC removable cable
Features: Crush resistant travel case, assorted eartips, 1/8” to 1/4” adapter, inline volume attenuator and wax loop for cleaning

Just like the UM3X RC, the packaging was an attractive box with photos and specs. Also included was the owner's manual on CD, multiple sized ear tips, was loop, and case. Only the case for the 4Rs is a water tight hard plastic case. And just like the UM3X RC, the materials used and fit and finish were excellent. Like they also have a detachable cable, which I am a huge fan of. The 4R’s are quite the investment, and a short in the cable can now be easily replaced.

Brunson Brothers: Fleace Movae, was very crisp and clean in the trumpets as well as the percussion.  They threw a very big soundstage with precise imaging.  And again the piano sounded natural.  Fresh Aire II: Going to Another Place, showed superb resolution.  The guitar was crisp and clean.  They use multiple different acoustic guitars.  Distinguishing the different ones as they play was easy.  But to hear the different nuances, like the decay of the guitar string after it is plucked, or the air being blown across the flute, was breathtaking!  Imaging was exact!  Steve Miller Band: Swingtown, had percussion that was crisp and clean, and bass that had good extension and played with authority.  Vocals were smooth, with excellent timbre.  The soundstage was quite large and imaging was excellent No Doubt: Hellagood, had percussion that was again crisp and clean and very dynamic.  The bass had good extension and played with authority.  Although I must admit that while it had good output, I was expecting a bit more with two bass drivers.  Stefani's vocals were nice and sultry.

Last but not least is the ACS T1. ACS is a company the focuses on IEM’s for the prosumer /audiophile, and professional musicians. In fact they have quite the list of endorsers, from some huge names such as Phil Collins, Pink Floyd, Radiohead and U2, to name just a few. When it comes to IEM’s it doesn’t get any better than custom made just for you. I’m sure you’ve heard the phrase party like a rock star? With the ACS T1’s you can listen like one.

Features and specs:
-Active Drivers:   3
-Build Material:   40 Shore Silicone with SterileTouch
-Mold Type:         Full Concha
-Cable Type:         Kevlar reinforced with anti-friction sheath
-Standard cable:  Translucent
-Standard color:   Clear
-Connector:          3.5mm gold plated molded
-Standard cable exit:   Top (over the ear)
-Frequency response:   16Hz - 20kHz
-Noise isolation:   26db
-Impedance:         17 Ohms
-Items included:   Carry pouch, personalized rugged case, wax pick, care and usage instructions, comfort     cream, step-up 1/4" jack connector adaptor

The ACS T1’s came in a hard plastic watertight case, with a custom tag and your name on it. They are after all custom made for you. Also included is the owner's manual, wax loop, cream and leather case. The quality of materials and the fit and finish were excellent. They use a medical grade silicone, and standard color is clear so you can see the individual components. With being able to see the components, coolness factor went way up. With an MSRP of $1000, you do get what you pay for. And you will be happy that they have detachable cables.

Purchasing a custom IEM from ACS is quite the experience. Once ordered, you will need to be custom fitted by a local Audiologist. In their office, they will inject silicone into each ear. The silicone takes around 5 minutes or so to harder, then it can be pullout out of your ear. These molds are then sent to ACS. About 4 weeks or so later, your custom IEM’s will arrive.  And once received, you won't be able to stop yourself from studying the components thru the clear medical grade silicone.  You can see the small red wire going from the insanely small PCB that contains the crossovers, to the 3 individual drivers. There are also the sound tubes that travel from the balanced armature drivers, to the exterior, which also have in-line acoustic filters.  How it was all made and fits together really is something to behold.  Sliding them in my ears....the fit was perfect.  And I must admit, it was very nice to not have to deal with trying on eartip after eartip, to find one with the perfect fit, or maybe just the best fit out of the eartips provided.

Brunson Brothers: Fleace Movae, was extremely crisp and clean in the percussion.  The trumpets sounded natural without being too brassy.  The resolution was phenomenal, being able to hear each and every individual 32nd note of the Flamenco guitar rifts by Struntz and Fara.  Fresh Aire II: Going to Another Place had amazing resolution in the acoustic guitars, just like with the Westone IEMs, being able to hear the fine subtle details, like the decay or fading of the guitar strings after they are plucked.  And being able to hear the breath of the flutist as they blow across the mouthpiece is just amazing.  The soundstage was also life-like, not just huge.  The imaging was exact, and harmonics were stellar.  It gave me goosebumps it sounded so good!  Steve Miller Band: Swingtown, the percussion was crisp and tight.  The piano sounded natural.  Vocals were silky smooth like the finest Swiss chocolates, and quite transparent, showing excellent timbre and texture!  Soundstage was again large with precise imaging.  It felt like I was right there in the recording studio with the band.  No Doubt: Hellagood, percussion was extremely dynamic.  The bass had great depth and punch with real impact.  Stefani's vocals were just sexy.

This year's group of IEM's was a nice one.  The Outdoor Research bluetooth wireless IEM's gave a nice sound.  Bluetooth performance was sketchy based on use with my laptop, and they sounded about what you would expect at their price point.  The real surprise for me was the Audiofly's AF-56.  The were built well and fit great and sounded much better than $100 should.  Not as good as the RBH EP2's, but much better than their price point.  And what I would call a bracket beater.  The Monster DNA as usual provided a great presentation and product, with a great sound for the money.  And I also liked the aluminum design of the RBH EP2.  They had a nice refined sound with a lot of resolution and impactful bass for a single driver.

The big surprise was going from those IEM's to the more ultra premium and multiple drivers of the Westone UMX3 and 4R's.  The difference was like difference between looking through a perfectly clean window, and a filthy one.  Yes, it was that big of a difference!  I had to force myself to stay focused, because I was enjoying the music so much and getting caught up in it.  These were songs I have listened to for a LONG time, yet I was provided subtle nuances in the music that I had not noticed before!  I guess that is probably the best compliment that I could give.....getting lost in the music, and helping us feel like it is a new experience.

The same can be said of the ACS T1's.  Getting caught up in the music, hearing new subtleties, I loved every minute they were in my ears.  Only with the ACS T1's, the experience was just a tad better.  It was like going from looking thru a perfectly clean window, to looking with the window rolled down and not in your way.  And having them custom molded and specially made just for you....how cool is that?!  Most guys like stereo gear and electronics.  Want to know what to get the guy that has everything?  ACS Custom IEM's!

This years group of IEM's was again quite good.  Based on their design, features, quality, and performance, the Audiofly AF56 and Monster DNA's have won our Recommended Award.  The RBH EP2 has earned our Highly Recommended Award.  And the Westone UMX3 & 4R, and ACS T1 has earned our Editor's Choice.  Although if we had a higher award, like an Editor's Choice Diamond Award, the ACS T1's would have gotten it, and the Westone's would have been really close.  For more info and complete specs, check out their websites at www.outdoorreaserch.com, www.audiofly.com, www.monstercable.com, www.rbhsound.com, www.westone.com, and www.acscustom.com.


Read more!

Sunday, March 31, 2013

2013 Annual Headphone Shootout Part One: The Over The Ear Models


It's March Madness time again, and that must also mean that it is also time for headphone manufacturers to go at it as well here at Stereowiseplus.com in our annual Headphone Shootout. We have all different styles, from over the ear featuring open and closed back, as well as in ear monitors. Some are even more specialty models, one over the ear from Motorhead designed and tuned for the rocker enthusiast. Then there is a truly custom molded in ear model from ACS. Today is part one of two parts, and features the over the ear design, from Motorhead, Audio-Technica, Jabra, Beyerdynamics, Monster, and Velodyne.




When it comes to March Madness, the teams are bracketed, based on the quality and performance of the team. And every year, some lower bracketed teams perform above their bracket, while some higher bracketed teams perform under their bracket. In most games, the higher bracket team wins, but sometimes a lower bracketed team will surprise. There are no brackets for headphones, just prices. And just as with the basketball teams, most models are accurately priced for their performance. But just as is with March Madness, sometimes there are surprises. Each model will be evaluated based on design, features, quality, and performance. And a listening test with several songs from different genres. Let the fun begin!


First up is a pair from Motorhead. Designed for rockers, to play loud, with their Moterizer model. They are a closed back DJ style design.


Features and specs:
-Microphone:     Yes, Controlizer
-Acoustic Design:     Dynamic, closed-back
-Driver:     ø40 mm, neodymium
-Sensitivity:     102 dB SPL (1mW) at 1KHz
-Frequency Response:     10 – 20,000 Hz
-Max Input Power:     200 mW
-Rated Impedance:      68 O 1KHz
-Earpad:     Velvet
-Headband Pressure:     Approx. 4.5 N
-Cable:     1 m (3.3 ft.) & 2.5 m (8.2 ft.) straight cable, single-sided
-Connector:     3.5mm gold plated stereo mini jack, 3.5 mm/6.3 mm adaptor


They came shipped in a box designed to look like a stage box that holds music gear for bands. They are mostly constructed of plastic with some rubber. They felt very durable. Construction quality and materials used, as well as fit and finish were good. They had cloth ear pads that felt soft. The Moterizer also felt comfortable on my head. I really liked the detachable cable! Included were two cables, one was much longer, and the other had built-in mic and Ipod/Cell phone controls. Also included is a cloth storage bag. MSRP is $129.


Brunson Brothers: Fleace Movae provided fairly crisp and clean trumpets, and good resolution. Bass extension was also good as was it's output. Fresh Aire II: Going To Another Place, percussion and strings were very crisp. Strings had great resolution and piano sounded natural. Bass output also had good authority. Steve Miller Band: Swingtown, yielded good resolution in the percussion and keyboard. Vocals sounded very natural. Guitar also sounded very good. Bass had good extension and output with punch. No Doubt: Hellagood had very good dynamics in the percussion. Bass had very good punch and played with authority. Vocals were smooth and had a lot of energy. The whole track had a lot of energy, and the Moterizer delivered in spades. The resolution was also quite good as well.


The Audio Technica ATH-AD500X is a pair of open back headphones. They are mostly plastic, with an aluminum mesh on the back. They features a wing system that helps them feel light when wearing them.




Features and specs:
•  Newly designed 53 mm drivers with CCAW voice coils reproduce remarkably natural sound, with deep, impactful bass and outstanding vocal projection
•  Open-air headphones produce no sense of pressure on the ears, resulting in a completely natural sensation
•  Lightweight honeycomb aluminum casing
•  Self-adjusting 3D Wing Support Housing provides comfortable support for a more enjoyable listening experience
•  Flexible raised-fabric earpads offer excellent wearing comfort and durability
•  Highly conductive OFC (oxygen-free copper) single-sided cable with elastic TPE sheath to prevent tangles
•  Gold-plated stereo 1/8" (3.5 mm) connector with 1/4" (6.3 mm) adapter
Type:     Open-air Dynamic
Driver Diameter:     53 mm
Frequency Response:     5 – 25,000 Hz
Maximum Input Power:     500 mW
Sensitivity:     100dB/mW
Impedance:     48 ohms
Weight:     235 g
Cable:     3.0 m (9.8')


The Audio-Technica ATH-AD500X came in an attractive box with a large plastic window to see the product. While they are mostly plastic in construction, the quality of components as well as the fit and finish is good. I liked the high quality cloth ear cup covers. Also included was a 1/4" plug adapter. The feel of their wing system is different, yet one that you get used to. And they were comfortable. MSRP is $169.


Brunson Brothers: Fleace Movae yielded good clean trumpets with good resolution. Bass extension was ok as was it's output. Fresh Aire II: Going To Another Place had crisp percussion. The flute had good air and the piano was natural sounding. Resolution of all the instruments was great. Steve Miller Band: Swingtown provided clean percussion with nice and smooth vocals. Bass had good extension and output with some authority. Guitars had nice resolution. No Doubt: Hellagood was very dynamic in the percussion. Bass had good low end extension and played with good output. Vocals were quite natural with a lot of energy.


Next up is the similar Audio-Technica ATH-AD700X. They are nearly identical to the ATH-AD500X in components and materials used in the construction, as well as their quality and the fit and finish, which is still good. The aluminum honeycombed casing on the back is also the same. The drivers used however are better, yielding a wider frequency response and power handling. MSRP is $199.




Features and specs:
•  Newly designed 53 mm drivers reproduce clear treble and midrange
•  Bobbin-wound CCAW voice coils for superior power handling
•  Full open-air type headphones produce no sense of pressure on the ears, resulting in a completely natural sensation
•  Lightweight aluminum honeycomb casing with excellent acoustic properties
•  Self-adjusting 3D Wing Support provides a comfortable listening experience; total ear-fit design minimizes pressure
•  Flexible raised-fabric earpads offer excellent wearing comfort and durability
•  Highly conductive OFC single-sided cord with elastic TPE sheath to prevent tangles
•  Gold-plated stereo 1/8" (3.5 mm) connector with 1/4" (6.3 mm) adapter
Type:     Open-air Dynamic
Driver Diameter:     53 mm
Frequency Response:     5 – 30,000 Hz
Maximum Input Power:     700 mW
Sensitivity:     100dB/mW
Impedance:     38 ohms
Weight:     265 g
Cable:     3.0 m (9.8')


Brunson Brothers: Fleece Movae had nice clean trumpets, nice resolution in the percussion, and bass extension was ok but did not provide much authority. Fresh Aire II: Going To Another Place, strings were extremely crisp with excellent resolution. Piano was natural sounding and the flute had good air. Bass had nice extension. Steve Miller Band: Swingtown, provided crisp and clean percussion with great resolution. The keyboard sounded natural as did the smooth vocals. Bass had ok resolution. No Doubt: Hellagood, had good dynamics in the percussion. Resolution was quite good with all the instruments. Bass had nice extension and punch. Vocals were quite sultry sounding. There was a lot of energy in the track, and it was brought out fairly well.


Next up is the Jabra Revo. It is a standard on the ear model. It does have a detachable cable. They are known for their wireless earpiece for cell phones, and this model is part of Jabras Music line.


Features and specs:
Connectivity: 3.5 mm Jack
Usage:
• Works with mobile phones
• Connects to a PC and can be used to stream music/sound and for voice calls
• Music Phone
• MP3
• Dolby Digital Plus
Frequency Response: Hifi
Microphone Type: Omni Directional/noise filter
Microphone Sensitivity: Standard (E-STD)
Wearing Style: Headband




The Jabra Revo came in a hard clear plastic case to show off the product. They looked like a premium product, and pulling them out of the box only confirmed that suspicion. They were constructed of metal, rubber and plastic materials of very good quality. The fit and finish was also very good. And they felt well made in hand. The earcups felt like a type of memory foam was used for a comfortable fit. And looking in the earcups was a piece of cloth that on one side said right and the other read left. It's a great touch that makes it easy to know you are putting them on right. And I loved the detachable cable. There is a connection for the cable on both earcups, so you can actually attach the cable to whichever side you prefer. Also included was a cloth storage bag and owners manual. MSRP is $199.


Brunson Brothers: Fleece Movae, there was nice resolution in the trumpets and percussion. Trumpets were nice and clean. Bass extension was very good, with the same output although a bit muddy. They also provided a good amount of energy. Fresh Aire II: Going To Another Place, provided very good resolution in the strings and percussion. Piano sounded natural. There was very good extension in the bass, which actually delivered some punch. Overall sound was just a tad warm. Steve Miller Band: Swingtown, had good resolution in the percussion and guitar. The keyboard sounded natural. Bass had nice extension with lots of authority. Vocals were also natural sounding. No Doubt: Hellagood, was extremely dynamic in the percussion. Bass had very good extension and played with serious authority. Vocals had great timbre and sounded natural. There was a lot of energy, and it all came out well!


The Beyerdynamics Custom One Pro is a DJ style over the ear headphones design. Unlike most over the ear headphones, these can be customized, in look and sound. The ends of the earcups allow for custom plates. There is also a 3 position slider on each earcup, to customize the bass output.


Features and specs:
•  Closed headphone
•  Variable bass reflex system
•  Versatile design with replaceable accessories
•  High efficiency due to 16-Ohm drivers
•  Rugged headband made of spring steel
•  Single-sided, plug-in type connecting cable
•  Soft, replaceable ear and headband pads
•  Gold-plated mini stereo jack plug (3.5 mm) & 1/4" adapter (6.35 mm)




The Beyerdynamics Custom Pro came in a attractive box with a clear plastic window so you can see the customizable earcups. They were mostly constructed of a high quality hard plastic, with some metal. The fit and finish was good as well. Also included was a soft storage case and owners manual.


Brunson Brothers: Fleece Movae, yielded good resolution and soundstage, with clean trumpets. Extension and output of the bass was quite nice, and also very clean. Fresh Aire II: Going To Another Place, the strings were crisp and clean and the flute had good air. Piano also sounded natural. The bass had impact, but not with a lot of authority. Steve Miller Band: Swingtown, had nice resolution in the percussion. Keyboard sounded natural as did the vocals, and had a nice sized soundstage. The bass sounded a tad subdued, but had a good low end extension and had some punch. No Doubt: Hellagood, had very good dynamics in the percussion. Bass extension was great and had lots of authority. Vocals were quite sexy. The sound was clean with a lot of energy. The Custom One Pro also had a customizable bass output settings on the side of each earcup, to custom tailor the bass output to your liking. Not only did it actually work, but it worked well!


Those of you who have Monster cable products know of their quality. For Monster, it is not just the product itself, it is also about the presentation. In those regards, the Monster Headphones Diamond Tear delivers in spades. They have an amazing design, look and feel.


Features and specs:
•  High-performance music headphone lets you feel like you are in the studio with the recording artists
•  Includes ControlTalk Universal Cable and Apple ControlTalk Cable, for calls through your headphones
•  Low profile, right-angle connector for a snag-free, secure fit
•  No-hassle, tangle-free cables lets you move freely
•  Monster Cleaning Cloth with advanced Aegis Microbe Shield





The Diamond Tears came in a gorgeous black box, with images and specs of the headphones. There was a small fabric tab at the bottom, and pulling up on the tab opened the box. Opening the box at the same time also raised at an angle the headphones! It was really something I had never seen before in packaging, and quite cool. The Diamond tears were of the very high quality materials as well. heir fit and finish was also extremely good. The materials used were mostly plastic, rubber and some metal. I loved the rainbow effect the sides have. They felt well put together in hand. While they are on the car design, they were still very comfortable to wear. Also included were detachable cloth cables, one of them with a built in mic and controls, a cloth case, and manual. There is actually a connector for the cord on both earpads, so you can have the cord on whichever side you prefer. MSRP is $329.


Brunson Brothers: Fleece Movae, there was very good resolution in the trumpets, which also sounded smooth. Percussion was crisp, and bass output and extension was great with plenty of authority. Fresh Aire II: Going To Another Place, provided crisp strings with very good resolution. Flute had good air and the piano was very natural. The drums had nice bass and the resolution was quite good. The bass also had nice extension and impact with authority. Steve Miller Band: Swingtown, the resolution was nice in the percussion, and the keyboard sounded natural. Vocals were smooth with good timbre. Resolution was actually quite good with all the instruments. Impact was good in the drums and had nice bass extension with authority. No Doubt: Hellagood, provided very dynamic in the percussion. Bass extension was very good and had good punch and played with authority. Vocals were sexy smooth and natural. All of the energy of the track came out in spades.


Second to last is the Velodyne vTrue. These are large premium headphones that feature an over the ear design. Velodyne first entered into the headphone market last year with the in ear vPulse. This year they continue with the introduction of even more models. The vTrue is their top of the line model. MSRP is $399.


Features and specs:
• Uncompromising studio sound quality for the most discerning audiophiles
• 50 mm drivers tuned to Velodyne's exacting standards
• Braided cloth tangle-resistant cables
• Dual 3.5 mm gold plated cable connectors
• Available in stylish Forged Aluminum & Brown Leather
• 4 foot, 3.5 mm (1/8") Y-cable connector
• 4 foot, 3.5 mm (1/8") Y-cable with control module
• 3.5 mm (1/8") to 6.35 mm (1/4") stereo adapter
• Carrying pouch
Driver size: 50 mm
Frequency response: 10 Hz – 20 kHz
Sensitivity: 96 dB/1 kHz/1 mW
Impedance: 24O
Power handling: 100 mW
Transducer type: Dynamic
Weight: 10.6 oz., without cable





The Velodyne vTrue came in a great looking hard box with a large picture on the front of the vTrue, as well as some specs. Opening the box revealed a great looking pair of large headphones. They were well protected in a custom foam cut-out, that they tightly slid into. The vTrue were constructed of plastic, metal and leather. The materials were of excellent quality as well as the fit and finish. They felt very solid and well put together in hand, worthy of the Velodyne name and tradition. I really liked the use of leather and the brushed aluminum on the ends covering the earcups, and the detachable cable. There were two high quality cloth covered cables, one with built-in mic and phone controls, as well as a cloth storage case.


Brunson Brothers: Fleece Movae, had very good resolution in the percussion. The trumpets were clean and very smooth and threw a nice soundstage. Bass was clean with plenty of extension with nice authority without being overly so. Fresh Aire II: Going To Another Place, had excellent resolution in the strings. The flute had good air. The piano was natural sounding, and they threw a nice soundstage. Bass had good extension, impact, and was natural sounding without having too much output. Steve Miller Band: Swingtown, gave very nice resolution in the percussion and keyboards. bass had good extension and impact. Vocals had great timbre and sounded natural. No Doubt: Hellagood, was very dynamic in the percussion. Bass had good extension and played with authority. Vocals were nice and smooth with great timbre. All of the energy came out very well.


Last but not least is the Beyerdynamics MMX300. They are an over the ear design, but also unique in that they are also designed for gaming. They feature an attached mic. So not only do they work well for music, but they also work well for gaming.


Features and specs:
•  Premium headset with carbon fibre look
•  Cockpit-tested audio components with impressive Hi-Fi quality reproduction
•  Closed-back design headphones
•  Excellent ambient noise attenuation (18 dBA)
•  Ergonomically-designed for superior comfort
•  Professional, noise-compensating condenser microphone for clear and precise voice quality
•  Robust steel headband construction with soft, replaceable ear and head cushions
•  Supplied with carrying case
•  "Made in Germany" with 5 years manufacturers warranty





The Beyerdynamic MMX300, like the Custom One Pro, came in an attractive looking box with a cut out to see the headphones. They are mostly made of plastic, with some metal and cloth. The quality of the materials used was very good. While the fit and finish is good, it just did not seem as solid or well built as they could have been. That is not to say they felt cheap. I was just expecting a tad more at their price point. And while it has built in mic, I would have expected a detachable one. MSRP is $415.


Brunson Brothers: Fleece Movae, had very good resolution. Trumpets were clean and crisp as was the percussion. All of the instruments had very good resolution. Bass extension was great with ok authority. Overall they were a tad bright sounding. Fresh Aire II: Going To Another Place, had crisp and clean strings. The flute had ok air, and the piano sounded natural. Bass extension was good, but with a bit subdued output. Steve Miller Band: Swingtown, provided very good resolution in the percussion and instruments. Vocals were natural with very good timbre. Bass had good extension without a lot of output. But the punch was there. They also threw a nice soundstage with good dynamics. No Doubt: Hellagood, had very good dynamics in the percussion, bass had very good extension and played with authority. Vocals came out smooth and sultry. All of the instruments came out with nice resolution and a lot of energy.


Since the MMX300 is a gaming headphone, we also tried them out with gaming. They were very comfortable to wear for long term gaming sessions. They sounded quite good for gaming as well. Sound effects all around me sounded real, and explosions had good depth. Sound quality of the built-in mic was also very good. While it would have been nice if the mic was detachable, it at least rotates up out of the way when not in use.


With this years over the ear participants, the performance of the models were pretty much as expected. The Motorhead Motorizer however did perform better than expected for their price point. The did not quite perform better than either of the Audio Technica's, but it was close. What the Audio-Technica's lacked it bass output, they made up in resolution, and vicea versa for the Jabra's. Monster delivered a home run in presentation, design, and performance in their Diamond Tears.  Another slight surprise was the Velodyne's. The bass was clean and deep, but for a company with an emphasis on hi-end subwoofers, I was expecting them to be tuned for more bass output. Not that they did not sound good, I was just expecting a little more low-end output. Although I am a bit of a basshead, and love a lot of bass.  Based on their design, features, and performance, the Motorhead Motorizer has earned our Value Award, the Audio-Technica ATH-AD500X and ATH-AD700X have both earned our Recommended Award. The Jabra Revo and Beyerdynamics Custom One Pro, and Beyerdynamics MMX 300 have earned out Highly Recommended Award. The Monster Diamond Tears and Velodyne vTrue have earned our Editor's Choice Award. For more info and complete specs, check out their websites at www.motorheadphones.com, www.audio-technica.com, www.jabra.com, www.beyerdynamic.com, www.monstercable.com, www.velodyne.com.






Read more!
